Surface‑Mounted Tire Killer (No Dig‑in Installation)
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
Description
Produit Paramoter
Many of our security project clients pick this tire killer for locations where digging roadway trenches is not feasible. Unlike traditional spike barriers that need underground embedding, this unit sits straight on top of existing road surfaces. It removes heavy civil construction work, which saves plenty of installation time and overall project budget.
The full control kit comes included with the unit, as shown in the product images: wireless remote fobs, onsite push‑button panel and main control cabinet. You can lift or lower the steel spikes via remote, or operate manually from the hard‑wired button station on site.
We fabricate the whole barrier from heavy‑duty A3 steel and coat it with anti‑rust paint. Black‑yellow warning reflective strips are painted on the surface, so drivers can spot the barrier clearly even under poor lighting. Custom paint colors are also an option if you need to match your site styling.
The steel spikes are 10 mm thick and reach 150 mm when fully raised. It can bear maximum load up to 80 tons, so fully‑loaded container trucks rolling over will not bend or damage the main body. Powered by electromechanical drive, the spikes complete rise and fall movement within 1‑2 seconds, responsive for daily gate access workflows.
Two control ranges you will want to note. Wireless remotes work steadily within 50 meters, while wired control supports up to 100 meters. It is rated IP67 waterproof, so rain and road splashes will not harm internal electronic parts. It runs reliably outdoors, handling working temperatures from ‑40℃ to +70℃. For long‑term storage when idle, keep the environment between ‑10℃ and 65℃.
Standard width is 500 mm. We supply common lengths of 3 m, 4 m, 5 m, 6 m, and custom length is available to fit your actual gate opening. Overall height ranges 70‑90 mm. The unit weighs roughly 0.5 ton, system dynamic power is 180W with AC220V power input.
This spike barrier fits factory gateways, security checkpoints, compound entrances and parking access control. Since ground excavation is unnecessary, it also performs well for temporary security deployment.
We accept bulk project orders. Reach out and share your gate dimensions and site conditions, we can work out a proper configuration for your project.
